2BBL Brite Tank (Jacketed)
This 2bbl brite tank, like all of our brite tanks, provide two huge benefits to brewers: Bright, clear beer and efficiency. Our bright tanks use geometry to provide the clearest beer possible. The dish shaped bottom allows remaining yeast or flocculation in the beer to settle into the dish. Because the beer is normally fairly clear when it is transferred into the brite tank, it is possible to take beer from the bottom drain of a bright tank without taking the yeast that has settled out, except for the first draw off of the tank.
Need to cost out your 2 bbl brewing system? Get a FREE quote from a Brewery Consultant.
BB2BBL-JKT (8050)
- Material: Premium virgin 304 stainless steel
Features of this 2bbl brite tank:
- Top Manway
- 80 Gallon Capacity
- Rated to 2-Bar (29 PSI)
- CIP arm and spray ball
- Sample Valve
- (2) 1.5" TC ports on side of tank for sampling and carbonation (carbonation stone sold separately)
- (2) 1.5" TC ports on top
- (1) 1/4" NPT fitting in CIP arm for sight glass tubing (tubing not included)
- (1) 1/4" NPT fitting in CIP arm for pressure gauge (sold separately)
- (2) 1.5" butterfly valves
- (1) 1/4" hose barb on bottom outlet tee for sight glass tubing (tubing not included)
- 1/2" NPT welded thermowell for contactless temperature probe
- Temp probes are available for purchase separately, with options for single tank-mounted, or multi-tank wirelessly accessible fermentation temperature control panels
- Diameter = 29.5"; Height = 61"; Steel Gauge = 3mm (main tank), 2mm (jacket/outer shell
Need a different size for your brewhouse? Check out these other jacketed brite tank options:
- 3 Barrel Brite Tank (Jacketed with Shadowless Manway)
- 4 BBL Brite Tank (Jacketed)
- 5 BBL Brite Tank (Jacketed)
- 6 BBL Brite Tank (Jacketed with Shadowless Side Manway)
- 7 BBL Brite Tank (Jacketed)
- 10 BBL Brite Tank (Jacketed with Side Manway)
- 15 BBL Brite Tank (Jacketed)
Prefer a non-jacketed brite tank? How about one of these:
- 37 Gallon Brite Tank (30 PSI) - (Non-Jacketed)
- 68 Gallon Brite Tank (with Butterfly Valves and Wheels) - (Non-Jacketed)
- 1 BBL (40 Gallon) Brite Tank (with Butterfly Valves) - (Non-Jacketed)
- 1 BBL (40 Gallon) Brite Tank (with Wheels and Butterfly Valves) - (Non-Jacketed)
- 2BBL BriteTank (Non-Jacketed with Cooling Coil) - (Non-Jacketed)
- 2BBL Brite Tank (68 Gallon with Butterfly Valves) - (Non-Jacketed)
- 3 Barrel Brite Tank - (Non-Jacketed)
- 3 Barrel Brite Tank (with wheels) - (Non-Jacketed)
- 4 BBL Brite Tank (with cooling coil) - (Non-Jacketed)
- 4 BBL Brite Tank (with wheels) - (Non-Jacketed)
- 4 BBL Brite Tank (with Butterfly Valves) - (Non-Jacketed)
- 5 BBL Brite Tank (Non-Jacketed with wheels) - (Non-Jacketed)
- 5 BBL Brite Tank (with butterfly valves) - (Non-Jacketed)
- 6 BBL Brite Tank (200 gallons) - (Non-Jacketed)
- 7 BBL (250 Gallon) Brite Tank (Non-jacketed with Side Manway)
| Weight (lb) | 410.000000 |
|---|---|
| Retail Price | $3,741.00 |
