5 BBL Brite Tank with Wheels (Non-Jacketed)
This 5 bbl brite tank is a popular tank for brewing craft beer, kombucha, cider and any other beverage that needs to be carbonated. This particular brite tank features wheels, which will allow the tank to be rolled out of your cold room for cleaning and/or kegging. Move the tank to the drain and water supply, eliminating the need for drainage and water in the cold room.
Quality-built and rated to 15PSI the Brite Tank receives the finished beer from the fermenter and can be used for carbonating or conditioning. It is perfectly matched to our 5 BBL brewing system for packaging or serving direct to the bar.
Need Help Costing Out Your 5 BBL Brewhouse? Get a Quote on Commercial Brewing Equipment
BB170WH (2550)
- Material: Premium virgin 304 stainless steel
- Maximum Capacity: 170 Gallons
Features of this 5 bbl brite tank:
- Wheels for easy maneuverability
- Non-jacketed
- Top manway
- (2) 1.5-inch Butterfly valves
- Lid has (1) 1/4-inch NPT-Male fitting and (1) 1/4-inch NPT-Female fitting for CO2 gauge and CO2 inlet/outlet
- Fittings and barbs for your sight glass tubing to measure liquid level in the tank (tubing not included; 1/4-inch draft beer hose is suggested)
Dimensions: 39.5" diameter x 61"H Rated 15 psi. 3mm wall thickness
Having trouble deciding? Here are some other non-jacketed brite tanks to consider:
- 3 Barrel Brite Tank - (Non-Jacketed)
- 3 Barrel Brite Tank (with wheels) - (Non-Jacketed)
- 4 BBL Brite Tank (with cooling coil) - (Non-Jacketed)
- 4 BBL Brite Tank (with wheels) - (Non-Jacketed)
- 4 BBL Brite Tank (with Butterfly Valves) - (Non-Jacketed)
- 5 BBL Brite Tank (with butterfly valves) - (Non-Jacketed)
- 6 BBL Brite Tank (200 gallons) - (Non-Jacketed)
- 7 BBL (250 Gallon) Brite Tank (Non-jacketed with Side Manway) - (Non-Jacketed)
Do you prefer using a jacketed brite tank? Try one of these options:
- 2BBL Brite Tank (Jacketed)
- 3 Barrel Brite Tank (Jacketed with Shadowless Manway)
- 4 BBL Brite Tank (Jacketed)
- 5 BBL Brite Tank (Jacketed)
- 6 BBL Brite Tank (Jacketed with Shadowless Side Manway)
Still don't see the brite tank size you are looking for? Please call us directly for customization options. (503) 372-9580
| Weight (lb) | 445.000000 |
|---|---|
| Retail Price | $5,393.00 |
