TOP SELLER!! - 3 BBL Mash Tun (Insulated)
Our insulated 3bbl mash tun is a great option the startup brewpub looking to make precision beer for on-site consumption. Insulation has the dual benefits of precise temperature control and safety. The single piece clamp-on lid can be outfitted with an optional hydrator along with recirculation ports available for vorlauf, sparge and HERMS.
The geometry and false bottom allow for a fluffy mash bed while still allowing a clear transfer of wort to the brew kettle. When the mashing is complete the manway allows for easy removal of spent grains.
Need Help Costing out Your 3 bbl brewhouse? Get started with a FREE commercial brewing system quote.
MT120TW-RF3-MW-INS (453)
- Material: Premium virgin stainless steel
- Capacity: 120 Gallons of brew
Features of this insulated 3 BBL Mash Tun:
- (3) Recirculating Fittings
- False Bottom
- Manway
- (1) Sanitary 1.5" butterfly valve
- (2) Sanitary Hose Barbs – 1/2"
- 1.5" Tri-Clamp Thermowell
- Dial Thermometer
- 1.5" Tri-Clamps and gaskets
- On Legs
- Dimensions: 32.5" diameter x 52.5"H. Lid adds approx. 4" to height
Need something a little bigger or smaller for your 3 bbl brewing system? Try one of these popular stainless steel mash tuns:
- 1 BBL Mash Tun (with Recirculating Fitting, Bottom Outlet and Legs)
- 2 BBL / 80 Gallon Mash Tun (with 3 Recirculating Fittings and Manway)
- 3 BBL Mash Tun (with 3 Recirculation Fittings)
- 4 BBL Mash Tun (Non-Insulated)
- 4 BBL Mash Tun
- 4 BBL Mash Tun (Insulated)
- 5 BBL Mash Tun (Insulated with Rakes and Plow)
Need to add cellar tanks to your brewery, winery or commercial facility? Here are some options to consider:
- 3 bbl Jacketed Fermenter (with top manway)
- 3 bbl Jacketed Fermenter (with side manway)
- 3 bbl brite tank (jacketed)
Custom options are available for all of our commercial brewing systems. If you have something specific in mind, let us know. We are easy to get ahold of and would be more than happy to discuss options.
| Weight (lb) | 370.000000 |
|---|---|
| Retail Price | $5,569.00 |
