3 BBL Brew Kettle - with Dome Top (Electric)
This 3 bbl brew kettle with dome top and top manway features old world craftsmanship with a mirror polished finish that will have any brewpub patron admiring your brewery.
Like most of our brew kettles, this 3 bbl brew kettle is also available with insulation (for energy efficiency) and bolted down footings (for safety).
Looking to Build or Expand your 3 bbl brewhouse? Get a FREE Quote on Commercial Brewing Equipment
BK145TW-TI-SG-EL4-LS1-MW-DOME (65)
- Material: Premium virgin 304 Stainless Steel
- Capacity: 145 gallons
Features of this 3 bbl electric brew kettle with dome top:
- Conical bottom for better trub and hop separation
- Tangential Inlet
- Thermowell
- Sight Glass
- Non-insulated (insulated kettles are available, just ask)
- Electric (Direct Fire kettles are also available)
- Offers a wider diameter for better evaporation
- Has a dome top for improved steam flow up and out of the kettle
- (5) ports for electric elements/level sensor
- (4) 1.5in. TC x 1in. NSP Adapters
- (1) 1.5in. TC x 1/2in. F-NPT Adapter
- (3) 1.5in. Butterfly valves, clamps/gaskets.
- Has Domed top with Manway.
- Dimensions: 35.5" diameter x 64"H (to top of steam exhaust port)
Not quite what you are looking for? Take a look at some of our other 3 bbl brew kettle options:
- 3 BBL Brew Kettle (Electric)
- 3 BBL Brew Kettle - with Domed Top and Bottom Heat Shield (Direct Fire)
- 3 BBL Brew Kettle - with Sloped Bottom (Direct Fire)
- 3 BBL Brew Kettle - with Sloped Bottom and Heat Shields (Direct Fire)
Prefer something a little bigger or smaller for your brewery? How about one of these options:
- 2 BBL Brew Kettle - with Burner Brackets (Direct Fire)
- 2 BBL Brew Kettle - with Tangential Inlet, Sight Glass, 3 Element Ports, 1 Level Sensor Port (Electric)
- 4 BBL Brew Kettle - with Conical Bottom (Electric)
- 4 BBL Brew Kettle - with Sloped Bottom, Heat Shields (Direct Fire)
- 5 BBL Brew Kettle - Insulated (Electric)
- 5 BBL Brew Kettle - Non-Insulated (Electric)
- 5 BBL Brew Kettle - with Dome Top, Bottom Heat Shield, Sloped Bottom (Direct Fire)
Need to add cellar tanks to your brewery, winery or commercial facility? Here are some options to consider:
- 3 bbl Jacketed Fermenter (with top manway)
- 3 bbl Jacketed Fermenter (with side manway)
- 3 bbl brite tank (jacketed)
Prefer to talk to someone about your needs? Give us a call at (503) 372-9580. We are easy to get ahold of and would love to help you find what you are looking for.
| Weight (lb) | 350.000000 |
|---|---|
| Retail Price | $4,546.00 |
