Oval Side Manway Door - 13" x 17"

In stock
Catalog
80-50
$669.00
  • Designed to be welded on to the side of a stainless steel vessel, this inward opening manway door is made of highly polished, sanitary 304L stainless steel.
  • The maximum pressure rating is 3 bar / 44 psi.  Includes the complete assembly, including the door, welding neck ring, hinge, tightening wing nut and a gasket made of EPDM.
  • A stainless steel handle is welded on the front of the door to assist with opening the door.

• Door openning 13" x 17", opens in-ward.

• Welding Neck Ring: 3"

• Door thickness 14 gauge (2 mm).

• Maximum pressure 45 psi.

More Information
Weight (lb) 45.000000
Micron 10 - 25 micron
85-50 (343.04 kB)
